Screw Clamp Terminal Blocks – Neutral & Earth Clamps – Connectwell CENC16

Feature

2.5 sq.mm Thermocouple Terminal Blocks.

These Terminal Blocks are used with thermocouple wires in measurement applications. As per DIN 43713 & DIN 43714 the current carrying element of the Terminal Block is made of the same material as the Thermocouple wire. These special current carrying elements ensure that there is no loss of potential at the connecting points.





Enquiry
16 sq.mm Neutral / Earth Clamps

The CENC series clamps are a flexible solution for terminating neutral and grounding wires on bus bar.

Specification

TECHNICAL DATA

Tightening Torque 2 Nm
Housing Material Polyamide
Product Function Neutral/Earthing Clamps
Wire Entry Orientation Side Entry
Mounting Possibility Panel/Surface
Screw Size M4
Operated by Screwdriver
Rated Surge Voltage 8 KV
Pollution Degree 3

CONNECTION DATA

Conductor Cross Section Stranded min. 10 mm²
Conductor Cross Section Stranded max. 16 mm²
Conductor Cross Section AWG/Kcmil min 10 AWG
Conductor Cross Section AWG/Kcmil max 4 AWG
Conductor Cross Section Stranded with Ferrule/Lug min 10 mm²
Conductor Cross Section Stranded with Ferrule/Lug max 16 mm²
2 Conductors with same Cross Section Stranded min 6 mm²
2 Conductor with same Cross Section Stranded max 10 mm²
2 Conductors with same Cross Section Stranded with TWIN Ferrule/Lug min 6 mm²
2 Conductor with same Cross Section Stranded with TWIN Ferrule/Lug max 10 mm²
Stripping Length 16 mm

DIMENSIONS

Length 23.3 mm
Width (Thickness) 9.8 mm



Ordering Code

CAT. NO. DESCRIPTION STD. PACK
CENC16 16 sq.mm Neutral/Earth clamps Terminal Block in Green colour 50
CENC16BU 16 sq.mm Neutral/Earth clamps Terminal Block in Blue colour 50
CENC16BK 16 sq.mm Neutral / Earth Clamps Terminal Block in Black colour. 50
CENC16G 16 sq.mm Neutral / Earth Clamps Terminal Block in Grey colour. 50

Download

Connectwell CENC16 Neutral _ Earth Clamps Screw Clamp Terminal Blocks-DpstarGroup
